BrandWABCO Original
Part TypePremium original quality
Technical SpecificationOE specification
Product CategoryDevice
Bolt lengths39.0 mm
Bolt threadsM16 x 1.5
Clevis pins16.0 mm
Distance between bolts120.6 mm
Max. operating pressure10.2/8.5 bar
Output force M14700 N
Port thread 11M22 x 1.5 JED - 152
Push-rod length70 mm
Push-rod threadM16 x 1.5
Release pressure5.8 bar
Return-spring force270 N
Stroke64/64 mm
Temperature range-40°C to +80°C
Total length274.0 mm
Type24/30
Type of operationCam
VersionWithout boot
YokeScrewed
Calculated Volume (dm³)25.34
Size (mm x mm x mm)440 x 240 x 240
UPCZ5
Weight (kg)10.14
Weight (lb)22.35
